Fireproof & Sound Systems

Gypsum boards have excellent fire resistance properties. Gypsum boards help prevent the spread of fire and also the expansion of fire to other rooms, helping reduce the damage caused by fire.

Stud Construction Method

High Sound Insulation Wall
for Fireproof Partition Wall

Xenna G Wall 76

Xenna G Wall 76

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD76

Application for where high sound insulation performance is required. Used for partition walls for music studios, movie theaters, and rooms with machinery.

Xenna G Wall 64

Xenna G Wall 64

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD64

Application for where high sound insulation performance is required. Used for partition walls for music studios, movie theaters, and rooms with machinery. Use of 21mm Reinforced Gypsum Board and 9.5mm Xenna G Board on top.

Xenna G Wall 21C・G

Xenna G Wall 21C・G

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD57

Application for where high sound insulation performance is required. Ideal for partition wall such as between rooms of hotels and condominiums. Noise is reduced by the staggered stud construction method and by wall thickness. Use 21mm Reinforced Gypsum Board and also 9.5 mm Xenna G Board.

Xenna G Wall 21C・G Security Specifications
(TGW2H-C・G security specifications)

Xenna G Wall 21C・G

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD61

Special specifications to prevent crimes in the partition wall such as rooms in hotels and apartments. Also, ideal if you want to improve the sound insulation performance. Security is insured by using zinc plated steel plate with a thickness of 0.8mm between the stud and 21mm board.

Equivalent to Sound Insulation Wall
Partition Wall of TLD50-45

Xenna G Wall 12C・G (TGW1H-C・G)

Xenna G Wall 12C・G (TGW1H-C・G)

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD53

Wall thickness can be reduced while having great sound insulation performances. Ideal for partition walls such as between rooms of hotels, and apartments. By having staggered studs it reduces the acoustic crosslinking. With this method you are also able to reduce wall thickness with having 12.5mm Reinforced Gypsum Board and also 9.5mm Xenna G Board.

Fireproof Wall 12C・G

Fireproof Wall 12C・G

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD50

Application where high sound insulation performance is required. Ideal for partition walls between rooms of hotels, apartments, and condominiums. While being a staggered stud construction method it reduces acoustics.

Fireproof Wall 12S・G (FPW1H-S・G)

Fireproof Wall 12S・G (FPW1H-S・G)

Fireproof Performance: 1 hour

Sound Insulation Performance : TLD43

Sound absorbing material filled in a conventional construction method, to ensure the sound insulation performance.
A fireproof sound insulation partition wall with reduced costs.
Used in areas such as dormitories, hotels and hallways of partition walls.

Fireproof Partition Wall

Xenna G Wall 12S (TGW1H-S)

Xenna G Wall 12S  (TGW1H-S)

Fireproof Performance: 1 hour

Thin wall thickness, which is ideal for partition walls for hospitals, schools, and office buildings.

Fireproof Wall 12S (FPW1H-S)

Fireproof wall 12S  (FPW1H-S)

Fireproof Performance: 1 hour

Fireproof partition wall for general purpose types with reduced cost and wall thickness, by using 12.5mm Reinforced Gypsum Board. Used for partition walls between the factory fire compartment and shops.

Fireproof Wall 15S (FPW15-S)

Fireproof wall 15S  (FPW15-S)

Fireproof Performance: 1 hour

Generic fireproof partition wall using 15mm Reinforced Gypsum Board.

One Side Fireproof Partition Wall

ST Wall Joint Processing Specification
(NewSTW Joint Processing Specification)

ST Wall joint processing specification

Fireproof Performance: 1 hour

Fireproof partition wall for single-sided construction. Ideal for general fire compartment wall.

ST Wall Underlay Reinforcement Specification
(NewSTW Underlay Reinforcement Specification)

ST Wall underlay reinforcement specification

Fireproof Performance: 1 hour

Fireproof partition wall for single-sided construction. Ideal for general fire compartment wall. Possible foundation finish of overlay joint.

ST Wall 100 (NewSTW100)

ST Wall 100  (NewSTW100)

Fireproof Performance: 1 hour

Fireproof partition wall which is single sided construction. Ideal for general fire compartment wall. Use studs in which are 100 inches or over.

Quasi-fireproof Partition Wall

Quasi-fireproof Wall 1212-S・G (QFW1212-S・G)

Quasi-fireproof wall 1212-S・G  (QFW1212-S・G)

Quasi-fireproof Performance : 1 hour

Sound Insulation Performance : TLD44

Application where sound insulation performance is required such as dormitories.

Quasi-fireproof Wall 912-S・G (QFW912-S・G)

Quasi-fireproof wall 912-S・G  (QFW912-S・G)

Quasi-fireproof Performance : 1 hour

Sound Insulation Performance : TLD42

Applications where sound insulation performance is required such as dormitories. Quasi-fireproof 45 minute partition wall.

Fireproof Structure of Columns and Beams

Fireproof Column 1H

Fireproof Column 1H

Fireproof Performance: 1 hour

A 1 hour fireproof structure of the pillars by dry construction method. Used in places in which you can see the pillars.

Fireproof Column 2H

Fireproof column 2H

Fireproof Performance: 2 hour

A 2 hour fireproof structure of the pillars by dry construction method. Used in places in which you can see the pillars.

Fireproof Beam 1H

Fireproof beam 1H

Fireproof Performance: 1 hour

A 1 hour fireproof structure for the beam by dry construction method. Used in places in which you can see the pillars.

▲
